Stage Liftregal

Vertical lift system

  • Increased storage capacity with a significantly smaller footprint
  • Large storage area with small footprint
  • Accurate stock inventory due to integration with internal ERP/WMS systems
  • More security and protection for operator and goods
  • Modular expandability

Vertical lift system (LRK)

The modular lift racking is a self-contained system in which trays are stored vertically on both sides of the unit. By reading a bar code or pressing a button, trays are automatically conveyed to the extractor located in the centre and transported from here to the service opening.

Due to the modular design, the LRK can be adjusted to the relevant height before or after installation.

The LRK reads each tray automatically – the products to be stored are then assigned to the ideal storage location at intervals of 25 mm. Depending on the room height, it is possible to save up to 85% on floor space in comparison with conventional systems.

The modular design of the LRK provides almost unlimited flexibility regarding the use of different ceiling heights.

The system height can be selected in 100 mm increments so that the lift racking always corresponds to the respective capacity and height requirements. Even if its location changes, the lift racking can be quickly adapted to the new conditions by adding or removing modules.

When used over several floors, up to 6 service openings can be integrated into the front and back of the LRC at any point; these can also be subsequently changed . The lift door in each service opening prevents draughts escaping and protects operators and stored goods.
